AFXDataDialog

This class is the base class for all data dialogs, which collect data from the user and typically collaborate with modes to process the data.

AFXDataDialog(mode, title, actionButtonIds=0, opts=DIALOG_NORMAL, x=0, y=0, w=0, h=0)

Constructor that creates a dialog box that occludes the main window.

Argument	Type	Default	Description
mode	AFXGuiMode		Host mode.
title	String		Title string.
actionButtonIds	Int	0	ID's of action buttons to be created.
opts	Int	DIALOG_NORMAL	Options and hints.
x	Int	0	X coordinate of origin.
y	Int	0	Y coordinate of origin.
w	Int	0	Width of the widget.
h	Int	0	Height of the widget.

AFXDataDialog(mode, owner, title, actionButtonIds=0, opts=DIALOG_NORMAL, x=0, y=0, w=0, h=0)

Constructor that creates a dialog box that occludes its owner widget.

Argument	Type	Default	Description
mode	AFXGuiMode		Host mode.
owner	FXWindow		Owner widget.
title	String		Title string.
actionButtonIds	Int	0	ID's of action buttons to be created.
opts	Int	DIALOG_NORMAL	Options and hints.
x	Int	0	X coordinate of origin.
y	Int	0	Y coordinate of origin.
w	Int	0	Width of the widget.
h	Int	0	Height of the widget.

addTransition(target, op, value, tgt, sel, ptr=None)

Adds a finite state transition to the dialog box. When the expression "target.getValue() op value" evaluates to True, an sel message will be sent to the tgt object.

Argument	Type	Default	Description
target	AFXIntTarget		Target.
op	AFXTransition::Operator		Operator type.
value	Int		Reference value.
tgt	FXObject		Message target.
sel	Int		Message selector.
ptr	String	None	Message data.

addTransition(target, op, value, tgt, sel, ptr=None)

Adds a finite state transition to the dialog box. When the expression "target.getValue() op value" evaluates to True, an sel message will be sent to the tgt object.

Argument	Type	Default	Description
target	AFXFloatTarget		Target.
op	AFXTransition::Operator		Operator type.
value	Float		Reference value.
tgt	FXObject		Message target.
sel	Int		Message selector.
ptr	String	None	Message data.

addTransition(keyword, op, value, tgt, sel, ptr=None)

Adds a finite state transition to the dialog box. When the expression "keyword.getValue() op value" evaluates to True, an sel message will be sent to the tgt object.

Argument	Type	Default	Description
keyword	AFXTogglableKeyword		Keyword.
op	AFXTransition::Operator		Operator type.
value	Int		Reference value.
tgt	FXObject		Message target.
sel	Int		Message selector.
ptr	String	None	Message data.

addTransition(keyword, op, value, tgt, sel, ptr=None)

Adds a finite state transition to the dialog box. When the expression "keyword.getValue() op value" evaluates to True, an sel message will be sent to the tgt object.

Argument	Type	Default	Description
keyword	AFXIntKeyword		Keyword.
op	AFXTransition::Operator		Operator type.
value	Int		Reference value.
tgt	FXObject		Message target.
sel	Int		Message selector.
ptr	String	None	Message data.

addTransition(keyword, op, value, tgt, sel, ptr=None)

Adds a finite state transition to the dialog box. When the expression "keyword.getValue() op value" evaluates to True, an sel message will be sent to the tgt object.

Argument	Type	Default	Description
keyword	AFXFloatKeyword		Keyword.
op	AFXTransition::Operator		Operator type.
value	Float		Reference value.
tgt	FXObject		Message target.
sel	Int		Message selector.
ptr	String	None	Message data.

addTransition(keyword, op, value, tgt, sel, ptr=None)

Adds a finite state transition to the dialog box. When the expression "keyword.getValue() op value" evaluates to True, an sel message will be sent to the tgt object.

Argument	Type	Default	Description
keyword	AFXBoolKeyword		Keyword.
op	AFXTransition::Operator		Operator type.
value	Bool		Reference value.
tgt	FXObject		Message target.
sel	Int		Message selector.
ptr	String	None	Message data.

bailout()

Performs checks to determine whether it is OK to cancel the dialog box. The implementaton of this class always returns True, and the derived class should reimplement this method to perform specific checks.

Reimplemented from AFXDialog.

getMode()

Returns the dialog box's host mode.

onKeywordError(kwd)

Handles the error that occurs when the given keyword or target contains invalid contents. This method will select the contents of the widget that is set for the keyword or target (with setWidgetForKeyword()). If no such widget is specified explicitly, it will select the contents of the widget that has the keyword or target as its message target.

Argument	Type	Default	Description
kwd	FXObject		Object that contains invalid contents.

onTableError(tableKwd, row, col)

Handles the error that occurs when the given table keyword or target contains an invalid element. This method will select the contents of the widget that is set for the element of the keyword or target (with setWidgetForKeyword()). If no such widget is specified explicitly, it will select the contents of the widget that has the keyword or target as its message target.

Argument	Type	Default	Description
tableKwd	FXObject		Object that contains invalid element.
row	Int		Row index.
col	Int		Column index.

onTupleError(tupleKwd, index)

Handles the error that occurs when the given tuple keyword or target contains an invalid element. This method will select the contents of the widget that is set for the element of the keyword or target (with setWidgetForKeyword()). If no such widget is specified explicitly, it will select the contents of the widget that has the keyword or target as its message target.

Argument	Type	Default	Description
tupleKwd	FXObject		Object that contains invalid element.
index	Int		Element index.

processUpdates()

Performs state processing during the GUI update cycles. This class provides an empty implementation of this method, and the derived class should redefine the method if it needs to process state updating.

Class flags

Message ID's.

ID_UPDATE_STATE

Used to update the state.

Global flags

Flags for data dialog box options.

DATADIALOG_BAILOUT

Perform bailout checks when the Cancel button is clicked.
