AFXSlider

This class provides a slider, which allows the user to specify a value by dragging its value indicator.

AFXSlider(p, tgt=None, sel=0, opts=AFXSLIDER_NORMAL, x=0, y=0, w=0, h=0, pl=0, pr=0, pt=0, pb=0)

Constructor.

Argument	Type	Default	Description
p	FXComposite		Parent widget.
tgt	FXObject	None	Message target.
sel	Int	0	Message ID.
opts	Int	AFXSLIDER_NORMAL	Options and hints.
x	Int	0	X coordinate of origin.
y	Int	0	Y coordinate of origin.
w	Int	0	Width of the widget.
h	Int	0	Height of the widget.
pl	Int	0	Left padding (margin).
pr	Int	0	Right padding (margin).
pt	Int	0	Top padding (margin).
pb	Int	0	Bottom padding (margin).

canFocus()

Returns True because a slider can receive focus.

Reimplemented from FXWindow.

disable()

Disables the slider.

Reimplemented from FXWindow.

enable()

Enables the slider.

Reimplemented from FXWindow.

getDecimalPlaces()

Returns the number of decimal points displayed.

getDefaultHeight()

Returns the default height.

Reimplemented from FXPacker.

getDefaultWidth()

Returns the default width.

Reimplemented from FXPacker.

getIncrement()

Returns the slider's auto-increment/decrement value.

getMaxLabelText()

Returns the maximum label's text.

getMinLabelText()

Returns the minimum label's text.

getRange()

Returns a sequence of ints (low, high) representing the widget's allowable minimum and maximum values.

getSliderStyle()

Returns the slider's style.

getTipText()

Returns the slider's tip text.

getTitleLabelJustify()

Returns the title label's justification mode.

getTitleLabelText()

Returns the title label's text.

getValue()

Returns the slider's value.

recalc()

Recalculates the slider. Redefined to handle slider movement.

Reimplemented from FXWindow.

setDecimalPlaces(dp)

Sets the number of decimal points displayed.

Argument	Type	Default	Description
dp	Int		Number of decimal places.

setIncrement(inc)

Sets the slider's auto-increment/decrement value.

Argument	Type	Default	Description
inc	Int		Increment.

setMaxLabelText(text)

Sets the maximum label's text.

Argument	Type	Default	Description
text	String		Max label text.

setMinLabelText(text)

Sets the minimum label's text.

Argument	Type	Default	Description
text	String		Min label text.

setRange(lo, hi)

Sets the slider's maximum and minimum values.

Argument	Type	Default	Description
lo	Int		Minimum value.
hi	Int		Maximum value.

setSliderStyle(style)

Sets the slider's style.

Argument	Type	Default	Description
style	Int		Style flag.

setTipText(text)

Sets the slider's tip text.

Argument	Type	Default	Description
text	String		Tip text.

setTitleLabelJustify(mode)

Sets the title label's justification mode.

Argument	Type	Default	Description
mode	Int		Justification mode.

setTitleLabelText(text)

Sets the title label's text.

Argument	Type	Default	Description
text	String		Title text.

setValue(value)

Sets the slider's value.

Argument	Type	Default	Description
value	Int		Value.

show()

Shows the slider.

Reimplemented from FXWindow.

Class flags

Message ID's.

ID_SLIDER	ID for the slider.
ID_LAST	Last ID for this class.

Global flags

options for tickmarks.

AFXSLIDER_HORIZONTAL	Slider shown horizontally.
AFXSLIDER_VERTICAL	Slider shown vertically.
AFXSLIDER_ARROW_UP	Slider has arrow head pointing up.
AFXSLIDER_ARROW_DOWN	Slider has arrow head pointing down.
AFXSLIDER_ARROW_LEFT	Slider has arrow head pointing left.
AFXSLIDER_ARROW_RIGHT	Slider has arrow head pointing right.
AFXSLIDER_INSIDE_BAR	Slider is inside the slot rather than overhanging.
AFXSLIDER_SHOW_VALUE	Show slider value.
AFXSLIDER_ABOVE_TITLE	Show slider above its title.
AFXSLIDER_AFTER_TITLE	Show slider after its title.
AFXSLIDER_NORMAL	Default slider options--slider is horizontal, inside the slot, and shown above its title label.
